Emu68 Hatcher¶
Build ready-to-run SD cards with pre-configured Workbench installation (+batteries included) for PiStorm-accelerated Amigas.
Runs on macOS, Linux and Windows.
- Bootable Emu68 install for PiStorm32-lite, PiStorm and PiStorm16
- Workbench 3.1, 3.2, 3.2.2.1 and 3.2.3 from stock ADFs, or AmigaOS 3.9 from the CD .iso including BoingBag 1+2; ROMs and disks are recognised by content, not by file name
- Workbench languages, Standard or GlowIcons icon set, HDMI output mode, Workbench screen mode and Framethrower / C790 native-video capture
- AGS import: copies the games, Work and Media partitions of an AGS image onto the card and starts AGS from Hatcher's own Workbench
- Customizable package set, filtered for the chosen OS and Emu68 version: MUI, WHDLoad+WHDLoadWrapper, IBrowse, HippoPlayer, ViNCEd, font packs, ... plus your own package files
- RTG via Picasso96, with optional full Picasso96.lha; experimental RGB2RTG for the A1200 with PiStorm32-lite
- Roadshow, MiamiDX or lwip-amiga networking with WiFi and Ethernet drivers, plus a Network Settings window on the Amiga; full Roadshow archive supported
- USB (Poseidon), NVMe and I2C real-time clock support
- Partition layout editor (PFS3 + FFS), optional per-partition "extra content" folder to pre-load Work / Data volumes (WHDLoad games, backups, ...)
- Build to an .img file (sparse by default), write it to an SD card after the build with optional verify, or write straight to the card
- Build configs as JSON (save / load)
- Update checks for the app and its signed package list
Support + Feedback¶
For questions, feedback, bug reports, feature requests, and project updates:
Please don't ask for support on other Amiga Discord servers
I won't be able to keep up with multiple channels, and the Emu68 Hatcher server is a better place for discussions plus I can post updates there more frequently.
Reporting an error
Attaching the right log file makes debugging way easier. See Troubleshooting for which file to grab depending on whether the build itself failed or something went wrong on the AmigaOS side.
Credits¶
Thanks to:
- mja65's fantastic work on the Emu68 Imager project
- Emu68 and Emu68-tools by Michal Schulz (MPL-2.0) - m68k emulation and the on-Amiga companion tools (EmuControl, VideoCore.card, WiFiPi.device, ...)
- hst-imager and hst-amiga by Henrik Stengaard (MIT) - disk image + RDB tooling
- Emu68P96Settings by flype44 - format reference for reading and generating Picasso96 settings
Bundled / downloaded at build time:
- WHDLoad
- Roadshow Demo bundled with permission from A. Magerl (APC&TCP)
- MiamiDX 1.0c downloaded from Aminet when selected
- 7-Zip (GNU LGPL) - downloaded at install time, License.txt copied alongside the binary
- emu68-driver-stack by rondoval - lwip-amiga, genet, USB and NVMe drivers, downloaded at build time
- Poseidon USB stack by Chris Hodges - downloaded from the iComp wiki when USB support is selected
- Aminet packages (MUI, HippoPlayer, IBrowse, akDatatypes, Picasso96, ...) - downloaded from aminet.net at build time; each ships its own readme with license
